| Specification: |
| |
| Working Surface |
: 1050 × 250 mm |
Distance from spindle centre to
underside of over support |
: 125 mm |
| Longittudinal feed |
: 600 mm |
| Cross feed |
: 230 mm |
| Vertical feed |
: 450 mm |
| Spindle Speed |
: 71/104/185/405/278//725 rpm |
| Number of feed |
: Three |
| Arbour |
: 25.4 mm |
| Spindle Bor |
: 17mm |
| Spindle Taper |
: ISO-40 |
| Electric Motor |
: 2 HP × 1440 rpm 3 Phase |
| No. Of Feed |
: Three (16mm/38mm/24mm perminute) |
| Coolant Pump |
: 0.11 kw, 2700 rpm |
| Floor Space |
: 550 × 980 mm |
| Height |
: 1500 mm |
| Coolant Tank Col. |
: 20 ltr |
|
|
|
