| Working Surface |
: 750 × 175 mm |
Distance from spindle centre to
underside of over support |
: 125 mm |
| Longittudinal feed (Auto) |
: 375 mm |
| Cross feed (Manual) |
: 100 mm |
| Vertical feed (Manual) |
: 225 mm |
| Spindle Speed |
: Six 65, 78, 102, 149, 295, 385, 562 rpm |
| Number of feed |
: Twelve |
| Arbour |
: 25.4 mm |
| Spindle Bore |
: 15 mm |
| Spindle Taper |
: ISO 30 |
| Electric Motor |
: 1 HP × 1440 rpm 3 Phase |
| Coolant Pump |
: 0.11 kw, 2700 rpm |
|
