| MODEL |
STCG-3 |
| Maximum Diameter of Cutter that Can be Grind |
: 250 mm |
| Maximum Distance Between Centers |
: 280 mm |
| Maximum Length of Clutting Edges Grind |
: 225 mm |
| Grinding Spindle Speeds |
: 4800 RPM |
| Swing Diameter on Standard Center & Workhead |
: 250 mm |
| Working Surface of Table |
: 330 X 125 mm |
| Longitudinal Traverse |
: 200 mm |
| Cross Traverse |
: 150 mm |
| Electric Motor |
: 0.5 HP 2800 RPM |
|
